Capillary thermostat WKC-70S2 16A/250VAC

Wishlist
Compare
Send
- VK
- WhatsApp
- Odnoklassniki
- Copy link

Model:
010.002.141

Adjustable capillary thermostat WKC-70S2 is intended for support of given temperature in the controllable device or its parts. Temperature adjusting range 10…70°C.
Electric rating: 16(3)A/250VAC.
Stainless steel bulb and capillary tube.

$5.05

pcs

Specifications

Bulb and capillary material	stainless steel
Temperature adjusting range	10°C…70°C
Temperature in position	H: 70±5°C L: 10°C;
Differential	5±3°C
Electric rating	С-1: 16(3)A/250VAC
Max temperature of the bulb	100°C
Max temperature of the case	150°C
Life	100 000 cycles

Thermostat dimensions

Capillary thermostat WKC-70S2 dimensions

Knob dimensions
