Thermostat FTS 01161.0-01

Name: Thermostat FTS 01161.0-01
Brand: Essima
SKU: 010.007.015
Price: 1.20 USD
Availability: InStock

Model: 010.007.015

−69%

Manufacturer: Essima

Thermostat (normally opened); contact breaker for regulating fans, cooling devices or other.

~~$3.93~~ $1.20

Available: 42 pcs

pcs

Technical Data

Sensor element	thermostatic bimetal
Contact type	snap-action contact
Service life	> 100,000 cycles
Max. switching capacity	250V AC, 5 (1.6)A
	120V AC, 10 (2)A
	DC 30W
Max. inrush current	AC 10A
Connection	2-pole terminal for 2.5mm², torque 0.8Nm max
Mounting	clip for 35mm DIN rail, EN 50022
Dimensions	47 x 33 x 33mm
Operating/Storage temperature	-20 to +80°C (-4 to +176°F) / -45 to +80°C (-49 to +176°F)
Protection type	IP20
