Axial fan YWF6D-710B-180/75-G, blowing

Model: 011.014.283
  • photo 3
  • photo 4
  • photo 5
  • photo 6
  • photo 7
  • photo 8
Axial fan YWF6D-710B-180/75-G
Axial fan YWF6D-710B-180/75-G on base with external rotor motor. Suitable for ventilation systems, refrigerators, air conditioning equipment, etc.
— Diameter of fan is 710 mm;
— Input power - 900/650 W;
— Voltage 380V/50Hz;
— Speed - 900/730 rpm;
— AirFlow at 20Pa - 14500/12015 m3/h.
$256.05
Available: 5 pcs
 pcs

Specification

Rated voltage380VAC
Frequency50 Hz
Rated current1.9 A - Δ
1.15 A - Y
Input power900 W - Δ
650 W - Y
Speed900 rpm - Δ
730 rpm - Y
Air volume at 20Pa14500 m3/h - Δ
12015 m3/h - Y
Noise level73 dB(A) - Δ
72 dB(A) - Y
Operating temperature-30°C...+60°C
Insulation classF
Bearingsball bearings
Motor protectionthermocontact (150±5)°C
Electrical connectionlead wire 7G 1,31mm2 + 2G 0,35mm2 length 100mm in terminal box connected
Direction of rotationcounterclockwise (CCW)

Dimensions

Dimensions of axial fan YWF6D-710B-180/75-G

Air flow curves

Axial fan YWF6D-710B-180/75-G air flow curves

Wiring diagram

Axial fan YWF6D-710B-180/75-G wiring diagram

Marking decoding YWF-4E-350-S-102/34-G:

  • YWF – external rotor fan series;
  • 4 – motor poles;
  • Е – motor type:
           E - single phase capacitor operation;
           D - three phases asynchronous operation;
  • 350 – the diameter of the fan blade;
  • S – air direction:
           S - sucking;
           B - blowing;
  • 102 – the diameter of the rotor;
  • 34 – the thickness of laminated core;
  • G – characteristics of the fan motor:
           G - grid;
           B - square frame.
