Axial sucking fan YWF6D-800S-180/105-G

Name: Axial fan YWF6D-800S-180/105-G
Brand: Weiguang
SKU: 011.014.307
Price: 347.33 USD
Availability: InStock

Model: 011.014.307

Axial fan YWF6D-800S-180/105-G on base with external rotor motor suitable for ventilation systems, refrigerators, air conditioning equipment, etc.

$347.33

Available: 33 pcs

pcs

Specification

Supply voltage	380VAC 50Hz
Input current	3.45A (Δ) 2.2A (Y)
Input power	1900W (Δ) 1300W (Y)
Speed	890 rpm (Δ) 700 rpm (Y)
Air flow	14159 m³/h at 140 Pa (Δ) 11961 m³/h at 100 Pa (Y)
Noise level	74 dB(A) (Δ) 72 dB(A) (Y)
Operating temperature	-30°C...+60°C
Insulation class	F
Blades material	aluminum
Degree of protection	IP55
Bearing type	ball bearings
Motor protection	Thermocontact 150±5°C
Rotation	CW (looking into the end shield)
Connection	terminal box
Net weight	35 kg

Marking decoding YWF-4E-350-S-102/34-G:

YWF – external rotor fan series;
4 – motor poles;
Е – motor type:
E - single phase capacitor operation;
D - three phases asynchronous operation;
350 – the diameter of the fan blade;
S – air direction:
S - sucking;
B - blowing;
102 – the diameter of the rotor;
34 – the thickness of laminated core;
G – characteristics of the fan motor:
G - grid;
B - square frame.
