KSD301M090HF1C

  • Model:
    010.010.116
  • Copy
KSD301M090HF1C
Manufacturer: Essima
Applicable to the temperature control of household electric appliance, such as water heater, water boiler, electric heating boiling bottle, electric disinfectant cupboard, dry cloth machine, micro-oven, electric heater and bathing heater. Also, it can be used for oven-temperature protection device of electrical machinery, rectifier equipment, daily electric appliance and all kind of electric heater.

Technical data

Contacts configuration1SPST-NC (normally closed)
Rated current16A
Rated voltage250VAC, 50/60Hz
Closed temperature(90±5)°C
Closed temperaturemanual
Dielectric strength1500VAC 50Hz for 1 minute
Max operating temperature170°C

Dimensions

KSD301M090HF1C dimensions
