Capillary thermostat WKB-40S1 16A/400VAC

Model: 010.002.134
  • photo 3
  • photo 4
  • photo 5
  • photo 6
  • photo 7
  • photo 8
Thermostat WKB-40S1
Adjustable single-pole capillary thermostat WKB-40S1 with handle with temperature range 0°...40°C is intended to maintain the required temperature in the controllable device or its parts. A rise in temperature causes the expansion of liquid within the bulb and capillary. The liguid acts on a bellows assembly within the plastic housing to open electrical contacts.
Area of application - conditioners, heaters, thermal veils.
Rated current 16A/400VAC.
$3.20
Available: 2756 pcs
 pcs

Specifications

Bulb and capillary materialstainless steel
Temperature adjusting range0°C ... 40°C
Temperature in positionH: 40 ± 3°C
L: 0 ± 5°C;
Differential5 ± 3°C
Electric rating16A/400VAC
Testing conditionstemperature changing rate ≤1K/min
Max temperature of the bulb70°C
Max temperature of the case125°C
Life100 000 cycles

Thermostat dimensions

Thermostat dimensions WKB-40S1

Handle dimensions

Handle with scale 0...40°C
