Capillary thermostat WKC-320S1 16A/250VAC

Model: 010.002.091
−43%
Thermostat WKC-320S1
Adjustable capillary thermostat WKC-320S1 is intended to maintain the required temperature in the controllable device or its parts. A rise in temperature causes the expansion of liquid within the bulb and capillary. The liquid acts on a bellows assembly within the plastic housing to open electrical contacts.
Breaking capacity 16A/250VAC.
Adjusting temperature range 66°C...320°C.
Capillary and bulb are made of stainless steel. Capillary length 2500 mm.
Grounding contact.
$4.20 $2.40
 pcs

Specifications

Bulb and capillary materialstainless steel
Temperature adjusting range66°C...320°C
Temperature in positionH: 320±12°C
L: 66±12°C;
Differential10±3°C
Electric rating16(3)A/250VAC
Testing conditionstemperature changing rate ≤1K/min
Max temperature of the bulb360°C
Max temperature of the case125°C
Life100 000 cycles

Dimensions

Capillary thermostat WKC-320S1 dimensions
